ST Fiber Patch Cord Connector Multimode / Singlemode Zinc Alloy For 0.9mm Cable

0.9mm ST Fiber Optic Connector, Single mode or Multi mode Optional, 100pcs/Pack

Description

0.9mm ST Fiber Optic Connector manufactured by ANC International Co., Limited are especially designed to provide low insertion loss and back reflection, along with high precision and mechanical stability. ST Means (Straight Tip) It has a bayonet mount that allows for quick connects and disconnects and a long cylindrical 2.5 mm ceramic ferrule to hold the fiber. The ST Connector body is made of nickel plated metal, which resist corrosion. They come with boots suitable for 0.9mm fiber cable diameters. ST connectors feature a screw-on collet that ensures precise connections in high vibration environments. These fiber optic connector kit comply with IEC 61754-13 and TIA 604-4-B, FOCIS-4 intermateability standards and conform to RoHS environmental requirements.

ANC fiber optic connectors kits are available in a variety of optical fiber connectors including, SC, LC, ST, FC, MT-RJ, MU, MPO, LX.5, FDDI, ESCON etc.

Specification

Recommended Cable Diameter: 0.9mm

Polishing: PC

SM and MM ST connectors optional

ST Boot Color: Black, Blue, Yellow, Green, Red, White etc.

Insertion Loss: < 0.3dB

Operating Temperature: -20° to +70° C

One-piece or Multi-piece ST Fiber Optic Connectors available

Features

Accurate mechanical dimensions

Low insertion loss, high return loss,

0.3um, 0.5um, 1.0um, 4.0um ferrule concentricity optional

Excellent compatibility and repeatability

Connector body is made of nickel plated metal, which resist corrosion.

Usage

Local Area Network (LANs)

Wide Area Networks (WAN),

Metropolitan Area Networks (MAN)

Data center, business, premises, FTTH and commercial applications

Optical Access Network

Optical CATV

Technical Data

fiber optic cable connectors

apc fiber connector

ST Fiber Patch Cord Connector Multimode / Singlemode Zinc Alloy For 0.9mm Cable Images
